Grid-connected mode: charges 24V batteries or operates as an adapter, with bypass output of the input AC power. Battery-only mode: works as an inverter to deliver 120V‑1200VA output.
Function Modules / Category / Description
Inverter
Output Power: 1200VA
Battery Input: 20~29.4Vdc
Inverter Output Voltage: 90~140Vac, typical 120Vac
Output Frequency: 60Hz
Output Waveform: Pure Sine Wave
Efficiency: Peak Efficiency ≥90%
AC-DC
Charging Power: 1200W
AC Input: 90~130Vac
AC Input Frequency Range: 47~63Hz
PF: 0.99 @100% Load
Charging Voltage: 29.4V
Charging Current: 40A
Efficiency: Peak Efficiency ≥91%
AC Bypass
Bypass Current Peak: Max: 16A
Environmental Conditions
Operating Temperature: -20℃～+40℃
Storage Temperature: -40℃～+70℃
Relative Humidity: ≤95%RH, non-condensing
Cooling Method: Forced Air Cooling
Altitude: ≤2000m
our casey
Lorem ipsum dolor sit amet consectetur adipisicing elit.
Product Features
High-efficiency forward bridgeless PFC + LLC topology for higher conversion efficiency.
Automatic CC/CV charging to effectively extend battery life
Full protection: over-temperature, over-voltage, over-current, short-circuit.
Bi-directional design: supports battery reverse output 120V AC pure sine wave.
Offline intelligent auto-switch between charging and inverting modes.
Product Features
Manual on/off control for flexible operation.
LED indicators for real-time working status.
Intelligent temperature-controlled fan for quiet & reliable cooling.
Bluetooth for FW upgrade, parameter setting and status monitoring.
Equipped with CAN & RS485 communication ports.
12s lifepo4 charger adopts a more scientific method, which is to choose a charger that automatically powers off.
FAQ
Q: What is a certificate?
Answer: We have CE, ROHS
Q: What is the payment term?
A: Most of them are 30% T/T prepaid, and the rest need to be paid before shipment.
Q: Do you provide guarantees for the products?
A: Yes, we provide a 12-month warranty for our products
Caution:
(1) When using the charger, children should be prevented from approaching and touching it.
(2) It is strictly forbidden to use or store flammable and explosive items near the charger.
(3) Please don't wash with water directly when cleaning the charger. It is recommended to use a clean cloth with a small amount of alcohol to wipe it.
