Combined Charger‑Inverter
Automatic operation mode: Supports automatic charge and discharge, with mains supply priority. During charging, if the bypass is loaded, bypass power takes priority and charging power decreases as bypass power rises. If there is no bypass load, full power is used to charge the battery. During discharge, the power module disconnects from the grid side and supplies power to the load via the bypass. When mains power is restored, the bypass automatically switches to mains supply and the module enters charging mode simultaneously.
Combined Charger‑Inverter
Output Power: 1200VA
Battery Input: 20~29.4Vdc
Inverter Output Voltage: 90~140Vac, typical 120Vac
Output Frequency: 60Hz
Output Waveform: Pure Sine Wave
Efficiency: Peak Efficiency ≥90%
AC-DC
Charging Power: 1200W
AC Input: 90~130Vac
AC Input Frequency Range: 47~63Hz
PF: 0.99 @100% Load
Charging Voltage: 29.4V
Charging Current: 40A
Efficiency: Peak Efficiency ≥91%
Combined Charger‑Inverter
Overheat safeguard: Two embedded NTC temperature sensors track thermal readings from the secondary heat sink and transformer in parallel. When readings captured by NTC exceed the preset trigger point, the unit activates shutdown protection. Normal working status restores automatically after temperature falls 10°C below the protection trigger value.
All products have passed the 100% aging test,Advanced equipment lets us obtain higher product output and quality,and also improve the overall qualification rate of products.
uangzhou Yunyang Electronic Technology Co., Ltd. as an original manufacturer, we can provide customized services for customers, control each production process, and control the price. Now we have global customers and also provide OEM services for global charger companies. If you have potential demand/quantity, please contact us for better price. As we are manufacturers, we can provide wholesale prices for customers.
FAQ
Q: What is the warranty of the charger?
A: The warranty period is 18 months.
Q: How will the goods be shipped?
A: We usually ship via UPS, DHL, FEDEX.
Q: Where is your main market for your products?
A: Most of our Suoer brand products are exported to Southeast Asia, Africa and Mid East.
Q:Can I have a sample order of Combined Charger‑Inverter?
A:Yes, we can provide an initial sample. But our samples are not free. We need to charge for the samples.
Q: Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
